Raised Floor Double (Twin) Cup Panel Lifter

Raised Floor Double (Twin) Cup Panel Lifter

PRODUCT DETAILS

Raised Floor Double Suction Cup Panel Lifter (Raised Access Floor Double Cup Tile Lifter) is one of the most useful raised floor lifting tools, allows installers and maintenance workers lift and remove individual tiles from a raised floor system easily and efficiently.

HuiYa Acceess Floor Double Suction Cup Panel Lifter - Raised Floor Twin Suction Cup Tile Lifter

HuiYa as a leading Access Flooring System Provider, also offer worldwide customers a series of high-quality raised floor accessories and tools, surely including the best Access Floor Lifting Tool - Raised Floor Double Cup Panel Lifter (Access Floor Twin Cup Panel Lifter).

Specifications

  • Cup Size: 4" & 5" Diameter Vacuum Suction Cups

  • Handle Long: 25 CM (Can Be Customized)

  • Material: ABS, Rubber, Aluminum Alloy

  • Color: Black, Orange, Red & More Colors (Can Be Customized)

  • Lift Capacity:

    Double 4" Cup Raised Floor Panel Lifters - Maximum 75 lbs Lift Load

    Double 5" Cup Raised Floor Panel Lifters - Maximum 50 lbs Lift Load

Raised Floor Double Suction Cup Panel Lifter (Raised Access Floor Double Cup Tile Lifter).jpg

Applications

  • Raised Floor Double 4" Cup Panel Lifters - All Woodcore and All Steel Raised Floor Panels

  • Raised Floor Double 5" Cup Panel Lifters - Concrete-filled Raised Floor Panels and All types of tiles from any raised floor systems

  • Also Ideal to Carry, Lift or Place Tiles, Glass, Marble or any Shiny Surfaced Objects (depends on the weight).

Features

  • Manufactured with high graded rubber and aluminum alloy, sophisticated production technology

  • Excellent adsorption capacity of suction cups ensure strong grip, no risk of falling

  • Designed by double cups allows easy lifting of heavy weights

  • Easy to use, help you lift and move access floor panels quickly and efficiently

  • Endures heavy manipulation, durable and long service life with replaceable cups

How To Use

Simply place the Access Floor Double Sucttion Cup Tiler Lifter (Puller) onto the your raised floor panel and press down, forcing out the air underneath the vacuum cups, and you will create a powerful vacuum hold. The suction is broken when the fingertip-operated bar is lifted.
